Veterinaria Animal Sperm Quality Analysis System Veterinary Cat Dog Sperm Analyzer Machine

1 / 5

Veterinaria Animal Sperm Quality Analysis System Veterinary Cat Dog Sperm Analyzer Machine

Classification:	Biochemical Apparatus
Type:	Biochemistry Analyzer
Certification:	ISO13485

Send Inquiry

Product Description

Basic Specifications

Model NO.

CCV-6800P

MOQ

1 Unit

Main Unit

19" LCD Display

Camera

JVC Professional Camera

Origin

China

Capacity

1000 units/Month

Product Introduction

Veterinaria Animal Sperm Quality Analysis System provides comprehensive and intuitive image data for veterinary diagnostics. Designed for cat, dog, and other animal semen analysis, this system combines high-resolution capture with advanced statistical software for professional results.

Software Features: Windows-based English interface with high-resolution image capture, processing, and automatic static/dynamic analysis. Capable of visual analysis, diverse query, data storage, and report printing.

Standard Configuration

Main Unit with 19" LCD Display
JVC Camera (Japan Technology)
NOVA Binocular Microscope
Microscope Analysis Software
Counting Plate & Thermostat
Microscope Slides & Manual

Technical Parameters

Category	Details
Motion Analysis	Curvilinear, Linear, and Average Path Motion
Velocity Classification	Class A (Rapid), B (Slow), C (Non-pre), D (Static)
Sample Collection	1-2000+ samples; Detection range 0-200 um/s
Image Capture	0-75 frames; Particle diameter resolution 1-10 um
Analysis Metrics	VAP, VCL, VSL, ALH, BCF, LIN, STR, WOB
Concentration	M/ML according to WHO standards

Morphology & Comprehensive Solutions

The system identifies swimming sperm head deformities and provides quantitative analysis of head size (area, perimeter, length, width) and tail normality.

Department	Available Medical Equipment
X-Ray Room	X-ray Machines, Processors, Films, Lead Protections
Ultrasound	2D/3D/4D Color Ultrasound Systems
Laboratory	Chemistry/Hematology Analyzers, ELISA, Centrifuges
Operation Room	Anesthesia, Ventilators, Lamps, Operating Tables
Patient Care	Patient Monitors, ECG, Infusion Pumps, Oxygen Generators

Frequently Asked Questions

What species can this sperm analyzer be used for?

The system is designed specifically for veterinary use, suitable for cats, dogs, and various other animals requiring reproductive analysis.

What are the main kinetic parameters detected?

It analyzes VAP (average rate), VCL (track speed), VSL (straight rate), ALH (head swing), and BCF (flogging frequency) among others.

Does the software support different languages?

Yes, the software features a Chinese-English changeable interface and runs on the Windows platform.

Is the analysis based on international standards?

Yes, the concentration and motility analysis follow WHO standards for accurate and professional diagnostic results.

What is included in the standard package?

The standard kit includes the 19" LCD main unit, a JVC camera, a NOVA microscope, professional analysis software, a thermostat, counting plates, and slides.

Can the system perform morphology analysis?

Yes, it identifies sperm head deformities and calculates dimensions like area, perimeter, length, and width of the sperm head.
