Basic Information
Transport Package
Standard Export Package
Production Capacity
500 units/Month
Core Features
3-part differentiation of WBC, 24 parameters include 3 histograms
Up to 70 samples test per hour, double channel counter
Electrical resistance for counting and SFT method of hemoglobin
10.4 inches touch screen operation (Mouse & Keyboard support)
Automatic diluting, mixing, rinsing and clog clearing
Automatic sample probe cleaning (inside and outside)
Internal thermal-sensitive printer & external printer support
Support for external barcode scanner
Open reagent systems (Closed systems optional)
LIS system connectivity supported
Technical Specifications
| Methodology | Electrical resistance for counting, hemiglobin cyanide method and SFT method |
| Parameter | 3-part differentiation of WBC; 24 parameters and 3 color histograms |
| Work mode | Double Channel + unique Hemoglobin test system |
| Sample volume | 9.6μL for Venous and capillary mode, 20μL for prediluted mode |
| QC control | X-B, L-J, X, SD, CV % |
| Reference Setting | Male, Female, Children, Neonate |
| Alarm | 25 test of alert messages |
| Temperature | 18ºC - 30ºC, Humidity ≤ 10-90% |
| Power supply | 220 V ±22 VAC, 50±1Hz |
| Dimension | 33 CM (L) * 38 CM (W) * 43 CM (H) |
| Weight | 20 KG |
Comprehensive Solutions
Frequently Asked Questions
How many samples can this analyzer test per hour?
The CCL-H900N is capable of testing up to 70 samples per hour using its efficient double channel counter system.
What parameters are included in the blood analysis?
The system provides a 3-part differentiation of WBC and measures a total of 24 parameters, including 3 detailed color histograms.
What is the required sample volume for a test?
It requires only 9.6μL for Venous and Capillary modes, and 20μL for Prediluted mode, making it suitable for various patient types including neonates.
Does the machine support LIS system integration?
Yes, the device is designed to be linked with LIS (Laboratory Information Systems) for efficient data management and transfer.
Is the system compatible with external printers and scanners?
Absolutely. While it has an internal thermal-sensitive printer, it also supports external printers (like HP1020) and external barcode scanners for streamlined workflow.
What kind of maintenance does the probe require?
The system features automatic sample probe cleaning for both the inside and outside, ensuring high hygiene standards and reducing manual maintenance tasks.
